Deviation Switch ROS-2 Product Description Stainless Steel Shell

Product Overview:ROS-2 deviation switch is a high-performance deviation detection device designed specifically for various belt conveyor systems. It is used to detect the deviation of the belt during operation, ensuring the safety and stability of the conveying system through real-time monitoring and alarm. This equipment is suitable for belt conveyors in industrial fields such as mining, metallurgy, chemical engineering, and power.

Main features:

1. High precision detectionThe ROS-2 deviation switch is equipped with a high-sensitivity sensor that can accurately detect the deviation of the belt, and can respond promptly even to small deviations.

2. Two level alarm functionThe equipment has a two-level alarm function, issuing a warning when there is slight deviation, and automatically triggering shutdown when there is severe deviation, reducing the risk of equipment damage and production interruption.

3. durableMade of high-strength materials, it has good impact resistance and corrosion resistance, suitable for use in various industrial environments.

4. Protection levelEquipped with waterproof and dustproof functions, the protection level is generally IP65, and it can work stably in harsh environments.

5. Easy installationCompact design, easy installation, can be quickly integrated into belt conveyor systems, reducing installation time and costs.

6. Wide compatibilitySuitable for belt conveyors of different specifications, supporting multiple voltage and signal output modes.

Technical parameters:

• working voltage：AC 220V / DC 24V
• Rated current：10A
• Protection level：IP65
• Detection angleAdjustable from ± 15 ° to ± 30 °
• output signal: Normally open/normally closed contact signal
• ambient temperature: -20 ° C to+60 ° C
• Shell materialAluminum alloy or engineering plastic
• Installation methodWall mounted or device side fixed

working principle:

The ROS-2 deviation switch is installed at a critical position in the belt conveyor system to monitor the real-time operation status of the belt. When the belt deviates, the built-in sensor will capture the deviation angle and trigger an alarm or shutdown function through the output signal. The two-level alarm system can issue a warning when the belt deviates slightly and automatically stop when it deviates severely, thereby preventing equipment damage and production interruption.

Application scenarios:

• miningBelt deviation monitoring for ore conveying systems to prevent equipment damage.
• metallurgySuitable for belt conveyor systems in high-temperature environments, ensuring stable operation.
• chemical industryMonitor the belt deviation during the transportation of chemical raw materials to ensure production safety.
• powerUsed for deviation monitoring in the coal conveying system of power plants to ensure the normal operation of equipment.

Installation and maintenance:

1. Installation locationIt is recommended to install the ROS-2 deviation switch at key positions on the belt conveyor, such as the head, tail, or turning of the belt, to ensure comprehensive monitoring.

2. Wiring operationFollow the product manual for correct wiring, ensuring stable electrical connections and stable signal transmission.

3. Adjust the detection angleAdjust the detection angle of the equipment based on the actual operating status of the belt to achieve the best monitoring effect.

4. Regular inspectionRegularly inspect the equipment to ensure that the sensors are working properly and the signal output is accurate. Check if the equipment is damaged or contaminated.

5. Cleaning and maintenanceRegularly clean the surface of the equipment to keep it dust-free and free of dirt inside, in order to prevent any impact on equipment performance.

Safety precautions:

• When installing and maintaining equipment, be sure to disconnect the power to prevent the risk of electric shock.
• Ensure that the equipment is installed securely and avoid damage caused by vibration or impact.
• When used in extreme environments, additional protective measures may be required to extend the lifespan of the equipment.

Summary:The ROS-2 deviation switch is a high-performance deviation detection device equipped with two-level alarm functions and high-sensitivity sensors, which can effectively monitor the deviation of the belt. Its sturdy and durable design and easy installation make it suitable for belt conveyor systems in various industrial environments, ensuring stable operation and production safety of the equipment.

Related Q&A FAQs:

1. How to adjust the detection angle of ROS-2 deviation switch according to different belt widths and conveying speeds?

Users may want to know how to adjust the detection angle of the equipment based on the actual belt width and conveying speed to ensure the best deviation detection effect.

2. How to set the two-level alarm function of ROS-2 deviation switch?

Users may need to understand how to configure the two-level alarm system of the device in order to trigger corresponding alarms or shutdown operations when the belt deviates to different degrees.

3. Do ROS-2 deviation switches require additional protective measures under extreme environmental conditions?

Users may be concerned about the service life and stability of the device in extreme temperatures, high humidity, or highly corrosive environments, and inquire whether additional protective measures or special versions of the device are needed.
